PCIe Protocol Analyzer

Protocol Analyzer


Application Notes

The PGY-PCIeGen3/4-PA is a PCIe Protocol Analyzer that supports protocol analysis up to PCIe Gen4 speeds. PCIe design and test engineers can easily capture and record traces at 2.5, 5.0, 8 and 16GT/s at a specific event and obtain error reports instantaneously at an affordable price. This enables the design and test engineers to reduce the development time and address the time-to-market needs. PCIe Gen4 data is captured using interposers between the root complex and endpoint (Device under test).PCIe Gen4 interposers support. PCIe Gen4 Protocol Analyzer’s software provides complete decode and error analysis of Transaction Layer Packets (TLPs), data link Layer Packets and with LTSSM information.

Key features

  • PCIe Gen1/2/3/4-X4 Protocol Decode and Analysis.
  • Currently supports four lane PCIeGen1/2/3/4 Bus.
  • Active M.2 Connector interposer for speeds up to PCIe Gen4 is standard offering with protocol analyzer.
  • Optional Passive M.2 Connector interposer for speeds up to PCIe Gen3.
  • Optional solder down probe tips for four lanes for speeds up to PCIe Gen3 (8Gbps)
  • Protocol Decoding of TS1, TS2, TLP, DLLP Packets.
  • Hardware based protocol packet TS1, TS2 and IDLE filter capabilities.
  • Software based search, filter-in and filter-out capabilities.
  • Hardware based protocol aware trigger capabilities.
  • Advanced multi-level if-then-else if trigger capabilities.
  • Standard buffer size of 16GB and expandable to 64GB combined for TX and RX.
  • Trigger based on TS1, TS2, TLP and DLLP Packet content.
  • Detailed view of each TLP/DLLP with all field values.
  • LTSSM Analysis for PCIe protocol traffic.
  • Memory segmentation with each segment with different trigger condition¹.
  • Trigger out signal at trigger event allows the triggering of other instruments such as an oscilloscope.
  • Interface to host system using USB 3.0.
  • Decoded data packets can be exported to .txt file for further analysis.
  • PGY Protocol Analyzer is light weight and can be deployed for on-site/ field tests.
  • Field upgradeable enables the unit to easy maintain for latest feature set.

       1. Will be supported in our future release

PCI Protocol Analyzer

Prodigy Interposers


Data Rates Supported

PCIe Gent, Gen2, Gen 3, Gen 4. (with Option PCIe4)

Link Width

Four lanes (Four TX and Four RX).


Active M.2 Interposer (Standard)

Solder Down Active Probes for speeds up to PCIe Gen3.(optional)

Protocol Decode


Trace Capture Size

Supports Continuous streaming of Protocol data to Host computer SSD/HDD. And Post Capture up to buffer size.


Based on TST TS2, TLP, DLLP.


Interface for Active probes. Trigger in/out SMA connectors.

Interface for Host Computer

USB 3.0

Host Computer Requirements

Processor: Intel i7 10" Generation or better (Equivalent)

Operating System: Windows 7/8.0/81/10 64bit OS RAM: minimum 1608 but the product would give a faster response for 3208/6408/more.

Storage: 25608 SSD or more (minimum storage capacity of 108 should be available in the hard disk drive. User can use more storage based on trace storage requirement)

Display resolution: 1024x768

Interface: Host computer should support USB 3.0 interface

Dimension (WxHxD)

(WxHxD) (205x5x25) cms.


Approx 4 kg

Power Requirement

12V 6A DC Power Supply (AC/DC Supplied along with Analyzer).
